Overview: 3/4” (19 mm) long-wearing single shoot tip with long carbide insert on the nose for highly abrasive conditions.
Packer Recommendation: 3/4” (19 mm) or wider.
Fertilizer Options: Used for seeding only.
Overview: The seed is placed in a 3/4” (19 mm) band onto a firm, unfractured seedbed. Fertilizer is delivered in a band off to the side (right or left) on the same level as the seedbed.
Packer Recommendation: 2-1/4” (57 mm) or wider.
Fertilizer Options: Granular or Liquid
Overview: 3-1/2” (89 mm) Paired Row liquid double shoot tip with 3/4” horizontal and no vertical seed/fertilizer separation.
Packer Recommendation: 3-1/2” (89 mm) or wider.
Fertilizer Options: Liquid
Overview: 4” (102 mm) Paired Row tip with extra long nose carbide and narrow carbide on the cutting edges of the wings. Two carbide inserts under the wings firm up the trench prior to seed placement.
Packer Recommendation: 4” (102 mm) or wider.
Fertilizer Options: Used for seeding only.
Not recommended for use on Case IH 800-900 or N P2070.
Overview: 4” (102 mm) Paired Row tip with horizontal and 3/4” (19 mm) vertical seed/fertilizer separation. Extra long nose carbide, narrow carbide on the cutting edges of the wings and under the wing to seal the fertilizer trench, and firm up the seed bed prior to seed placement.
610-TIP-4082 has additional carbide along the sides of the fertilizer trench, below the wings, to provide extra wear life. Not recommended for use on Case IH 800/900 or NH P2070.
Packer Recommendation: 4” (102 mm) or wider.
Fertilizer Options: Granular, Liquid, NH3, Pressurized NH3 and NH3 + Phosphorus
*Drawings for illustration purposes only. All measurements shown are approximate. Results may vary with multiple factors including soil conditions, ground speed, application rates, fan speeds and more. In less than ideal conditions, mixing between seed and fertilizer may occur. For more information please refer to our precautions and risk factors.
Notes:
*When installing on a 50° shank other than Bourgault or Ezee-On use wedge 880-WDG-0300 or 880-WSG-0301.
**Recommended for use with 3/4” single shoot tip 610-TIP-0802.
***Use bottom holes when mounting for use with 0802, 1711, 1712 & 3500 tips. To make this opener 3/4″ deeper use top holes when installing the holder. See page 126-127 for more information.
****Not recommended for use with Paired Row Tip 610-Tip-4081.
*****Use the bottom two holes when installing this holder for standard installation. To add 3° more pitch, use the top two holes on the holder.
For a more detailed view check out the expanded drawing.
Precision Drills NH3
1/2” O.D. Stainless Tube
For pressurized NH3 order this tube and consult with your pressurized system dealer for tubing inserts.
C-Shank Drills NH3
1/2” O.D. Stainless Tube
For pressurized NH3 order this tube and consult with your pressurized system dealer for tubing inserts.
Precision Drills Liquid
1/4” O.D. Stainless Tube
C-Shank Drills Liquid
1/4” O.D. Stainless Tube
Precision Drills Liquid or NH3
3/8” O.D. Stainless Tube
C-Shank Drills Liquid or NH3
3/8” O.D. Stainless Tube
Precision Drills Aqua NH3 + Phos
1/4” O.D. Stainless Tube
C-Shank Drills Aqua NH3 + Phos
1/4” O.D. Stainless Tube
